YCBS45 Heat Shrink Wrapper

No.YCBS45
It adopts continuous fork-type bottle separation. Automatic parameter adjustment via touch screen enables easy adaptation to various bottle types and packaging combinations.
The shrink tunnel is externally accessible for convenient maintenance. The thickened thermal insulation layer delivers high energy efficiency and precise temperature control.
The independently servo-controlled vacuum belt conveyor ensures stable conveyance of 0.05 mm ultra-thin film to cut costs.
The infeed conveyor and main
  • YCBS45 Heat Shrink Wrapper,Hanmei Machinery,YCBS45 Heat Shrink Wrapper

Description

Model: YCBS45ZT
Packaging Speed: 45 trays/min
Overall Dimensions: L 21465 × W 1800 × H 2700 mm
Conveyor Width: 686 mm
Shrink Tunnel Dimensions: L 3000 × W 700 × H 450 mm
Air Consumption: 300 NL/min
Max. Pack Dimensions: Width 180–300 mm, Length 240–420 mm
Working Air Pressure: 0.6–0.8 MPa
Power Supply & Total Power: 3-phase 5-wire, 380V, 95 kW
Total Weight: 6000 kg
