YCBS130 Heat Shrink Wrapper

No.YCBS130
YCBS130 Heat Shrink Wrapper
It is fitted with a film unwinding unit and constant-tension film conveying system. With instant film cutting and automatic overlapping wrapping, the finished shrink packages feature higher structural strength.
It adopts vibration-type bottle separation, which prevents bottle jamming and squeezing and ensures smooth conveying.
Powered by a servo motor control system, the bottle pusher, film feeding, cutting and wrapping movements are precisely synchronized for stable
  • YCBS130 Heat Shrink Wrapper,Hanmei Machinery,YCBS130 Heat Shrink Wrapper

Description

YCBS130 Shrink Wrapper

Model: YCBS130
Packaging Speed: 130 packs/min
Overall Dimensions: L 19600 × W 1800 × H 2500 mm
Conveyor Width: 686 mm
Shrink Tunnel Dimensions: L 3000 × W 1000 × H 650 mm
Air Consumption: 80–100 NL/min
Max. Pack Size: L 460 × W 280 × H 345 mm
Working Air Pressure: 0.6–0.8 MPa
Power Supply & Total Power: 3-phase 5-wire, 380V, 95 kW
Total Weight: 5500 kg
